Size: 4-1/2” to 20” (114.3mm to 508mm)
Grade: J-55, K-55, L-80, N-80, P-110
Length: R1 (4.88mm to 7.62mm), R2 (7.62mm to 10.36mm), R3 (10.36mm to 14.63mm)
End: BTC, LTC, STC, Premium Connection
Thread: 8RD, 10RD
Pipe body: Seamless
Standard: API 5CT & 5B

Usage: Casing serves as the structural retainer for the walls of oil and gas wells, or wellbore. It is inserted into a well bore and cemented in place to protect both subsurface formations and the wellbore from collapsing and to allow drilling fluid to circulate and extraction to take place.

Annual Supply Capacity: 200,000 tons

Features: purified steel; stable chemical composition; good quality surface; high accurate dimension; perfect mechanical and workmanship.

Quality Control System:

• Size and surface inspection.

• Non-destructive test.

• Thread inspection.

• Hydrostatic test.

• Drifting test.

• Physical and chemical analysis.

• Hardness and pressure test.

Parameters for Casing

Label (a)		Outside Diameter	Nominal Linear Masses(b.c) T&C	Wall Thickness	Type of End-finish
1	2	D	Kg/m	t	H40	J55	L80	N80-1	P110
1	2	mm	Kg/m	mm	H40	K55	L80	N80-Q	P110
4-1/2	9.50	114.30	14.14	5.21	S	S	_	_	_
4-1/2	10.50	114.30	15.63	5.69	_	SB	_	_	_
4-1/2	11.60	114.30	17.26	6.35	_	SLB	LB	LB	LB
4-1/2	13.50	114.30	20.09	7.37	_	_	LB	LB	LB
4-1/2	15.10	114.30	22.47	8.56	_	_	_	_	LB
5	11.50	127.00	17.11	5.59	_	S	_	_	_
5	13.00	127.00	19.35	6.43	_	SLB	_	_	_
5	15.00	127.00	22.32	7.52	_	SLB	LB	LB	LB
5	18.00	127.00	26.79	9.19	_	_	LB	LB	LB
5	21.40	127.00	31.85	11.10	_	_	LB	LB	LB
5	23.20	127.00	34.53	12.14	_	_	LB	LB	LB
5	24.10	127.00	35.86	12.70	_	_	LB	LB	LB
5-1/2	14.00	139.70	20.83	6.20	S	S	_	_	_
5-1/2	15.50	139.70	23.07	6.98	_	SLB	_	_	_
5-1/2	17.00	139.70	25.30	7.72	_	SLB	LB	LB	LB
5-1/2	20.00	139.70	29.76	9.17	_	_	LB	LB	LB
5-1/2	23.00	139.70	34.23	10.54	_	_	LB	LB	LB
6-5/8	20.00	168.28	29.76	7.32	S	SLB	_	_	_
6-5/8	24.00	168.28	35.72	8.94	_	SLB	LB	LB	LB
6-5/8	28.00	168.28	41.67	10.59	_	_	LB	LB	LB
6-5/8	32.00	168.28	47.62	12.06	_	_	LB	LB	LB
7	17.00	177.80	25.30	5.87	S	_	_	_	_
7	20.00	177.80	29.76	6.91	S	S	_	_	_
7	23.00	177.80	34.23	8.05	_	SLB	LB	LB	_
7	26.00	177.80	38.69	9.19	_	SLB	LB	LB	LB
7	29.00	177.80	43.16	10.36	_	_	LB	LB	LB
7	32.00	177.80	47.62	11.51	_	_	LB	LB	LB
7	35.00	177.80	52.09	12.65	_	_	LB	LB	LB
7-5/8	24.00	193.68	35.72	7.62	S	_	_	_	_
7-5/8	26.40	193.68	39.29	8.33	_	SLB	LB	LB	LB
7-5/8	29.70	193.68	44.20	9.52	_	_	LB	LB	LB
7-5/8	33.70	193.68	50.15	10.92	_	_	LB	LB	LB
7-5/8	39.00	193.68	58.04	12.70	_	_	LB	LB	LB
7-5/8	42.80	193.68	63.69	14.27	_	_	LB	LB	LB
7-5/8	45.30	193.68	67.41	15.11	_	_	LB	LB	LB
7-5/8	47.10	193.68	70.09	15.88	_	_	LB	LB	LB
8-5/8	24.00	219.08	35.72	6.71	_	S	_	_	_
8-5/8	28.00	219.08	41.67	7.72	S	_	_	_	_
8-5/8	32.00	219.08	47.62	8.94	S	SLB	_	_	_
8-5/8	36.00	219.08	53.57	10.16	_	SLB	LB	LB	LB
8-5/8	40.00	219.08	59.63	11.43	_	_	LB	LB	LB
8-5/8	44.00	219.08	65.48	12.70	_	_	LB	LB	LB
8-5/8	49.00	219.08	72.92	14.15	_	_	LB	LB	LB
9-5/8	32.30	244.48	48.07	7.92	S	_	_	_	_
9-5/8	36.00	244.48	53.57	8.94	S	SLB	_	_	_
9-5/8	40.00	244.48	59.53	10.03	_	SLB	LB	LB	_
9-5/8	43.50	244.48	64.73	11.05	_	_	LB	LB	LB
9-5/8	47.00	244.48	69.94	11.99	_	_	LB	LB	LB
9-5/8	53.50	244.48	79.62	13.84	_	_	LB	LB	LB
9-5/8	58.40	244.48	86.91	15.11	_	_	LB	LB	LB
10-3/4	32.75	273.05	48.74	7.09	S	_	_	_	_
10-3/4	40.50	273.05	60.27	8.89	S	SB	_	_	_
10-3/4	45.50	273.05	67.71	10.16	_	SB	_	_	_
10-3/4	51.00	273.05	75.90	11.43	_	SB	SB	SB	SB
10-3/4	55.50	273.05	82.59	12.57	_	_	SB	SB	SB
10-3/4	60.70	273.05	90.33	13.84	_	_	_	_	SB
10-3/4	65.70	273.05	97.77	15.11	_	_	_	_	SB
11-3/4	42.00	298.45	62.50	8.46	S	_	_	_	_
11-3/4	47.00	298.45	69.94	9.53	_	SB	_	_	_
11-3/4	54.00	298.45	80.36	11.05	_	SB	_	_	_
11-3/4	60.00	298.45	89.29	12.42	_	SB	SB	SB	SB
13-3/8	48.00	339.72	71.43	8.38	S	_	_	_	_
13-3/8	54.50	339.72	81.10	9.65	_	SB	_	_	_
13-3/8	61.00	339.72	90.78	10.92	_	SB	_	_	_
13-3/8	68.00	339.72	101.19	12.19	_	SB	SB	SB	SB
13-3/8	72.00	339.72	107.15	13.06	_	_	SB	SB	SB
16	65.00	406.40	96.73	9.53	S	_	_	_	_
16	75.00	406.40	111.61	11.13	_	SB	SB	_	_
16	84.00	406.40	125.01	12.57	_	SB	SB	_	_
18-5/8	87.50	473.08	130.21	11.05	S	SB	SB	_	_
20	94.00	508.00	139.89	11.13	SL	SLB	_	_	_
20	106.50	508.00	158.49	12.70	_	SLB	_	_	_
20	133.00	508.00	197.93	16.13	_	SLB	_	_	_
S-Short round thread, L-Long round thread, B-Buttress thread.
a. Labels are for reference and assistance in purchase order. b. Nominal linear masses, threaded and coupled (col.2) are shown for reference only. c. The densities of marten site chromium steels (L80 type 9Cr and 13Cr)are different from carbon steels. Therefore, the masses values shown above are not accurate to marten site chromium steels. A mass correction factor of 0.989 may be used. d. C90, T95 and Q125 casing shall be furnished with sizes, masses and wall thickness shown above or on the purchase order.
